340BH

Bunkhouse, three slides, outside kitchen

Floorplan of RV model 340BH
MSRP:$77,253*
Base price. Does not include freight, title, tax, options or dealer fees.
Build & Price
Floorplan of RV model 340BH
Specifications
Specification Name Specification Value
RV Type Travel Trailer
MSRP $77,253
Shipping Weight 8,930 lb.
Carrying Capacity 2,070 lb.
Hitch 1,160 lb.
Length 37 ft 11 in
Height 11 ft 4 in
Tire-Size ST225/75R15E
Fresh Water 54 gal
Gray Water 76 gal
Waste Water 38 gal
Sleeping Capacity 10
Number of Propane Tanks 2
LPG 60 lb.
Refrigerator Size 10 cu ft

Standards & Options*

Standard
Optional

*Throughout the year, Keystone RV may modify model features, floor plans, and specifications. Website data typically reflects the most recent production run, however, any or all of these items are subject to change without notice. Please check with your dealer to for the details specific to the unit you are purchasing. You should also read all labels that are on each trailer for information concerning the safe operation of the unit and its components, actual weight(s), cargo carrying capacity, and tire information. MAKE SURE YOUR TOW VEHICLE IS COMPATIBLE WITH YOUR KEYSTONE RV. Owners of Keystone recreational vehicles are solely responsible for the selection and proper use of tow vehicles. For more information about the safe operation and use of various systems, Keystone service warranties and how to obtain service, extended use, towing, and maintenance, click here to review the Keystone Owner’s Manual. Component and appliance manuals can be found in the trailer.

Decor

Cashmere

Cashmere
Cabinetry
Countertop
Flooring
Accent Fabric
Cashmere Upholstery

Click swatches for close-up view.

Decor

Liam

Liam
Cabinetry
Countertops
Flooring
Liam Upholstery
Accent Fabric

Click swatches for close-up view.
Floorplan of RV model 340BH

340BH

Bunkhouse, three slides, outside kitchen

Floorplan of RV model 340BH
MSRP:$77,253*
Base price. Does not include freight, title, tax, options or dealer fees.
    Floorplan of RV model 340BH
    Specifications
    Specification Name Specification Value
    RV Type Travel Trailer
    MSRP $77,253
    Shipping Weight 8,930 lb.
    Carrying Capacity 2,070 lb.
    Hitch 1,160 lb.
    Length 37 ft 11 in
    Height 11 ft 4 in
    Tire-Size ST225/75R15E
    Fresh Water 54 gal
    Gray Water 76 gal
    Waste Water 38 gal
    Sleeping Capacity 10
    Number of Propane Tanks 2
    LPG 60 lb.
    Refrigerator Size 10 cu ft

    Standards & Options

    Exterior

    • 10 1/2" BAL Norco huck bolted "Z" channel frame
    • 10 1/2" BAL® Norco huck bolted "Z" channel frame
    • Power tongue jack
    • Pinch rolled laminated gel-coated fiberglass exterior
    • Large panoramic black framed tinted 80% safety glass windows
    • Painted fiberglass front cap w/ LED strip lights and rock guard
    • Fully walkable 3/8" roof decking and one-piece TPO membrane
    • Rear ladder
    • Norco cable driven slide system w/ manual slide backup
    • One-piece polypropylene heated enclosed underbelly
    • 5,100 lb. Dexter® E-Z Lube axles w/ 10" electric brakes
    • Leaf spring suspension system
    • MORryde® Suspension
    • 15" radial tires on aluminum wheels w/ spare
    • 15" Maxxis Radial Tires w/ spare
    • BAL Norco 5.1 stabilizing system
    • BAL® Norco 5.1 stabilizing system
    • BAL Norco 7.3 auto-leveling
    • BAL® Norco 7.3 auto-leveling
    • Friction-hinge entry door w/ self closing screen door and oversized grab handle
    • Friction Hinge Door
    • LCI® SolidStepâ„¢ w/ extra-wide first step
    • Slapshot Screen Door
    • MORryde® Telescoping Grab Handle
    • Back-up camera prep
    • Suburban Stow Away Entry Steps
    • Slam-latch baggage doors w/ magnetic door holders
    • Back-Up Cameral Installed
    • Side Marker Camera Prep
    • Keyed Alike
    • Double welded dual battery brackets w/ battery disconnect
    • Water docking stations
    • 54 gal. fresh, 38 gal. gray, 76 gal. black
    • Outside kitchen
    • 50-AMP shore power line
    • Outside shower
    • Lighted power awning w/ adjustable arms
    • Under Body LED Lighting
    • Slide Topper Prep
    • Exterior Storage Lighting
    • TPMS
    • Full Body Paint - Royal Gold
    • Full Body Paint - Obsidian

    Interior

    • Thomas Payne collection theater seating
    • Fiber-glass backed linoleum floor w/ no carpet
    • Extra tall slide height
    • Real Touch 3D high-definition fascia covering
    • Black out roller shades
    • Designer upholstered window valances
    • Pre-drilled and screwed hand-glazed modern cabinetry
    • Thomas Payne® collection theater seating
    • Theater seating IPO tri-fold sofa
    • LED Accent Lighting Under Island
    • 78" arched interior ceilings
    • Power Pro Smart RV System w/ Voice Command
    • Fireplace
    • Interior sliding barn doors
    • LED lighting throughout

    Keystone Exclusives

    • 3-year limited structural warranty
    • 1-year limited base warranty
    • Color-coded unified wiring standard
    • 4G LTE and Wi-Fi prep
    • Tuf-Lokâ„¢ thermoplastic duct joiners
    • KeyTVâ„¢ multisource signal controller
    • In-floor heating ducts
    • Tru-fitâ„¢ slide construction
    • Hyper Deckâ„¢ flooring
    • HyperDeckâ„¢ flooring
    • Blade Pureâ„¢

    Kitchen Features

    • Hardwood Cabinetry
    • Solid surface kitchen countertops
    • Deep, single basin stainless steel sink w/ 3" drains and rollup sink cover
    • High-rise faucet w/ pull-out sprayer
    • Dream Dinetteâ„¢ w/ max-store
    • Free-standing dinette

    Appliances & Utilities

    • Dual 30 lb. propane bottles w/ auto changeover
    • 15K BTU A/C w/ true race track ducting
    • 18K BTU Chill Cube A/C
    • 2nd A/C
    • 35K BTU furnace
    • On Demand Hot Water Heater
    • 40"/50" HDTV and AM/FM/CD stereo w/ DVD payer, MP3 hookup and Bluetooth® enabled
    • 10 cu.ft. 12V GE refrigerator
    • Microwave
    • 3-burner gas range and 21" Furrion® stove w/ low pro hood vent
    • LED Batten Strip Interior Lighting
    • 55-AMP converter

    Bedroom Features

    • Decorative bedspread and pillow package
    • Queen size bed w/ built-in pet kennel storage
    • Reading lights
    • Bedside outlets/USB
    • Decorative bedspread
    • TV hook-up

    Bathroom Features

    • Pressed bathroom countertops
    • Power roof vent and skylight over tub
    • Porcelain foot-flush toilet

    Weather Protection

    • Elementsâ„¢

    Safety

    • Breakaway switch and safety chains
    • GFI receptacles
    • Carbon monoxide detector
    • Smoke detector
    • Propane gas leak detector
    • Fire extinguisher
