SolarFlex Ready

Not quite ready for a solar power package? SolarFlex Ready provides owners with the basics to add solar later.

SOLARFLEX READY COMPONENTS
  • 30A solar roof port w/ MC4 connectors & 10 AWG MPPT solar charging circuit
  • Inverted 110v loop prep with up to 7 outlets (inverter not included)
  • Zamp Solar portable solar panel charge port

GO TO SOLARFLEX READY QUICK START GUIDE

WHAT YOU CAN EXPECT

Keystone's SolarFlex Ready is a budget option that allows owners to scale into solar if they choose.

EXPLORE BRANDS FEATURING SOLARFLEX READY

Bullet (single-axle floorplans); Cougar (SE models only); Fuzion Impact Series (aluminum sidewall models); Hideout; Passport Mini; Springdale; Raptor Carbon Series (aluminum sidewall models)

LEARN ABOUT OTHER SOLARFLEX PACKAGES

SolarFlex Protect 220; SolarFlex Discover 440i; SolarFlex Outlast 660i-L; SolarFlex Outlast Extreme 1320i-L

RETURN TO SOLARFLEX HOME PAGE
EXPAND YOUR SYSTEM

Easily add solar power to RVs prepped with SolarFlex Ready. All parts are availalbe through a Keystone authorized dealer or service center.

ADD SOLAR ENERGY COLLECTION*

ADD SOLAR ENERGY COLLECTION* + FASTER CHARGING

  • Install a second 220w Future Solutions panel (KRV part #) and upgrade from a 15A solar charge controller to a 30Amp solar charge controller (KRV part# 679077)

ADD SOLAR POWER FOR 110V OUTLETS

  • Install 2000w inverter in inverted prep circuit -- Xantrex (KRV part# 653865) or Magnum (KRV part# 686127) recommended
  • *SolarFlex supports a maximum of two panels per roof port.
TECHNICAL SPECIFICATIONS

SOLAR PANEL MECHANICAL SPECIFICATIONS (EACH)

  • Approximate Dimensions: 39.37"H x 41.34""W X 1.38"
  • Approximate Weight: 29.76 lbs.
  • Frame: Anodized Aluminum Alloy
  • Cable Length: 35.43"L
  • Number of Cells (Pcs): 66 (6x11)
  • Hail Impact Test: 227g steel ball dropped from 1M height
  • Cell Size: 3.27" x 6.59"
  • Cell Type: Monocrystalline
  • Connectors: MC4
  • Encapsulate: EVA
  • Junction Box: IP68

SOLAR PANEL ELECTRICAL SPECIFICATIONS (EACH)

  • Maximum Power (Pmax) : 220
  • Maximum Power Voltage (Vmp): 35.75V
  • Maximum Power Current (Imp): 6.15A
  • Open Circuit Voltage (Voc): 44.2V
  • Short Circuit Current (Isc): 6.28A
  • Power Tolerance: +/-3%
  • Maximum System Voltage: 600UL/1000V/ IEC
  • Module Operating Temperature: -40°C to +85°C

CHARGE CONTROLLER SPECS

  • Enclosure: IP43 (electronic components); IP22 (connection area)
  • Protection: PV reverse polarity; output short circuit; over temperature
  • Standard(s) Listings: EN/IEC 62109-1; UL 1741; CSA C22.2
